(XT-60) Parallel charging Board 2~6S

Multi-Pack Simultaneous Charging: Charges up to six lithium battery packs (2S to 6S) in parallel at the same time using a single balance charger, reducing field charging time significantly.

Standard XT60 Connectors: Equipped with high-current XT60 main power output ports for direct compatibility with RC drone, airplane, and vehicle LiPo/LiFe battery packs.

Integrated JST-XH Balance Ports: Features dedicated 2S, 3S, 4S, 5S, and 6S JST-XH balance leads on-board to balance individual cell voltages across all connected battery packs.

Short Circuit & Overcurrent Protection: Built-in resettable fuse protection circuitry prevents short circuit damage caused by accidental cross-cell connection or voltage mismatches.

Thick Copper PCB Traces: Engineered with heavy-duty 2oz copper traces to safely handle continuous high-current balancing and fast charging up to 30A total.

Includes Charger Connection Cables: Comes complete with a heavy-gauge XT60 main input lead and 6S JST-XH balance adapter cable for seamless connection to standard bench balance chargers.

Housing & PCB Style: High-density double-sided FR-4 glass epoxy PCB with heavy copper traces, protective insulating backing pad, and onboard JST-XH sockets.

Contact & Terminal Style: Gold-plated brass pins inside high-temp nylon XT60 housings and nickel-plated JST-XH balance pin headers.

Technical Specifications:

Supported Cell Count: 2S to 6S LiPo / LiFe / Li-ion.

Max Continuous Current: 30A total across ports.

Input Connectors: 4mm banana plugs / XT60 input to charger with 6S balance lead.

Output Connectors: 6 x XT60 power ports & 6 x JST-XH balance ports (2S–6S).

Color: Black PCB with yellow XT60 ports and white JST-XH sockets.

Usage Advice: Only connect batteries of the same cell count (e.g., all 3S or all 4S) and similar state of charge/voltage prior to plugging into the parallel board.

Maintenance: Keep board contacts clean, dry, and free of metallic debris or flux residue. Store in a protective anti-static pouch when not in active use.

Essential High-Volume Field Charging Hub: Position as an indispensable accessory for FPV drone pilots, RC aviators, and race craft operators looking to multiply their charging throughput without carrying multiple standalone chargers.

Highlight Built-in Fuse Protection & Time Savings: Emphasize the onboard fuse safety features along with the time saved by charging six battery packs concurrently during race days or field sessions.

Recommended Cross-Sell Add-ons: Pair with A400 40W Battery Balance Charger 3-4S, Lipo Battery USB Converter XT60, TP5100 4.2V/8.4V Li-ion Battery Charging Module, and ESD antistatic mat 50x40CM PCB Welding Mat.

Featured Collection Star: Display prominently on your Battery Charger Accessories collection page under multi-pack balancing staging.
