UNI-T UT61D+ 1000V True RMS Digital Multimeters

High-Precision 6000-Count True RMS Display: Delivers accurate True RMS measurements for complex, non-linear AC voltage (1000V) and AC/DC current (20A) with a high-resolution 6000-count backlit screen and analog bar graph.

Peak Hold & Relative Mode Functions: Captures transient surges and voltage spikes as fast as 250us with Peak Hold, while Relative Mode (REL) zeroes out stray resistance/capacitance.

LoZ Low-Impedance & LPF Measurement: Features LoZ low-impedance input to eliminate ghost voltage readings across unenergized lines, plus a Low-Pass Filter (LPF) mode for stable measurements on VFD motor drives.

Non-Contact Voltage (NCV) & Audible/Visual Alarms: Integrated optical and acoustic NCV sensor safely identifies live wires, paired with input terminal LED guidance and overvoltage warning alarms.

USB Data Transmission & PC Connectivity: Equipped with a USB communication interface for real-time data logging, long-term monitoring, and analytical charting via PC software.

CAT III 1000V / CAT IV 600V Heavy-Duty Protection: Rated for maximum safety with full input overload protection to safeguard technicians in demanding commercial and industrial electrical environments.

Housing & Construction: Industrial double-injection molded ABS casing with protective shock-absorbing rubber holster, integrated rear tilt stand, and built-in test lead holders.

Electrical Safety Ratings: Certified to IEC 61010 CAT III 1000V / CAT IV 600V high-voltage protection standards.

Power Source & Included Accessories: Powered by 4 AAA batteries (1.5V). Package includes safety test leads, USB interface cable, multi-purpose socket, and user manual.

Maintenance & Cleaning: Clean the exterior housing and LCD screen using a dry microfiber cloth. Keep USB port and input terminals free from bench dust and moisture.

Industrial & Electrical Benchmark Meter: Position as an advanced, high-precision True RMS multimeter tailored for electrical engineers, plant maintenance teams, and commercial HVAC specialists.

Highlight Peak Hold, LoZ, & PC Logging: Emphasize its 250 µs Peak Hold capture, ghost-voltage elimination (LoZ), and USB data logging capability as high-tier diagnostic features for field and laboratory work.

Recommended Cross-Sell Add-ons: Pair with Uni-T Test Lead CAT III 1000V/CAT IV 600V 20A, UNI-T UT181A True RMS Datalogging Multimeter, UNI-T UT195E Professional Multimeter AC/DC 1000V 20A, and 1 Pair Small Test Hook Clip to Banana Plug.

High-Margin Professional Featured Unit: Feature as a flagship professional choice on your Digital Multimeters collection page to capture high-value commercial and industrial orders.
