Mean Well HDR-30-24 9-36V Input, 24V/1.25A Output

Ultra-Slim DIN Rail Design: Compact 35mm (2SU) wide housing mounts directly onto standard TS-35/7.5 or TS-35/15 DIN rails, saving critical space inside industrial control cabinets.

30W 24V Regulated Output: Efficiently converts low DC input voltage into a stable 24V DC output up to 1.25A (30W max) for industrial control equipment, PLCs, and automation systems.

Wide DC Input Compatibility: Accepts a flexible wide DC input voltage range of 9V–36V DC, ideal for solar power arrays, battery-backed installations, vehicle electronics, and low-voltage bus systems.

Fine-Tuning Voltage Trim: Onboard potentiometer (V_ADJ) allows fine calibration of the 24V output rail (21.6V–29V) to offset line resistance loss over longer cable runs.

Class II Insulation (No Ground Pin Required): Flame-retardant plastic enclosure engineered to Class II safety standards, eliminating the need for an Earth ground connection.

Comprehensive Multi-Protection Suite: Integrated circuit protection guards against output short circuits, continuous current overload, over-voltage spikes, and input reverse polarity.

Housing & Casing Style: Flame-retardant step-shaped plastic casing (UL94V-0) engineered for TS-35 DIN-rail mounting and natural convection airflow.

Contact & Terminal Style: Touch-safe screw terminal block connectors (DC Input: +Vin, -Vin; DC Output: -V, +V).

Technical Specifications:

Model: HDR-30-24.

Input Voltage: DC 9V–36V.

Output Voltage: DC 24V (Adjustable 21.6V–29V).

Output Current: 0A–1.25A Max.

Rated Power: 30W

Cooling: Passive air convection (fan-less design).

Color: Industrial Grey enclosure with red/white Mean Well logo.

Usage Advice: Size continuous loads to 80% of total maximum rated capacity (1A / 24W) for long-term operational stability. Maintain vertical airflow space around upper and lower cabinet vents.

Maintenance: Ensure top and bottom casing vents remain free of dust and debris accumulation. Designed for indoor distribution panels and control cabinets.

Essential DC-DC Converter Unit: Position as the ultimate solution for stepping up low-voltage DC power (e.g., 12V battery banks, solar arrays, mobile systems) to clean, regulated 24V power for industrial sensors, PLCs, and relays.

Highlight Wide 9-36V Input & DIN Rail Mounting: Emphasize its wide DC input flexibility combined with an ultra-slim 35mm DIN-rail form factor that makes integrating 24V equipment effortless in battery-driven setups.
