ISDT Q8 500W 20A Battery Balance Charger 1-8S

500W High-Power Output: Delivers up to 500W of total charging power with a maximum 20A charging current to rapidly replenish high-capacity LiPo/LiFe/Li-ion battery arrays.

Wide 1S–8S Cell Range: Supports balance charging for 1S to 8S multi-cell lithium battery packs, perfect for high-performance RC vehicles, racing drones, and heavy-duty robotics.

Full Multi-Chemistry Support: Versatile compatibility across LiPo, LiFe, LiHV, Li-ion, NiMH, NiCd, and Pb battery chemistries.

IPS Full-View Color Screen: Features a bright, high-contrast 2.4-inch IPS LCD screen for clear visibility and real-time monitoring under full daylight conditions.

Advanced scOS 2.0 Interface: Powered by ISDT’s fast and intuitive scOS 2.0 operating system, enabling smooth navigation, customizable preset charging profiles, and firmware upgradeability.

Comprehensive Safety Systems: Built-in protection against overcurrent, overvoltage, overtemperature, reverse polarity, and abnormal cell voltage conditions to safeguard your battery investments.

Housing & Casing Style: High-strength, heat-resistant engineering polymer housing designed with optimized internal ventilation and integrated cooling fan.

Contact & Terminal Style: Standard XT60 main power input/output connectors and 8S JST-XH balance socket array.

Technical Specifications:

Input Voltage: DC 10V – 34V.

Output Voltage: DC 1V – 34V.

Charge Current: 0.1A – 20.0A.

Discharge Current: 0.1A – 1.5A.

Max Charge Power: 500W.

Max Discharge Power: 15W.

Balance Current: 1.5A per cell max.

Supported Cell Counts: LiPo/LiFe/Li-Ion/LiHV (1-8S), NiMH/NiCd (1-16S), Pb (1-12S).

Color: Black housing.

Usage Advice: Requires an external DC power supply (10V – 34V) capable of matching your intended charge wattage. Always connect the balance lead prior to starting high-current balance charges.

Maintenance: Ensure the cooling fan intake and exhaust vents remain clean and unblocked during operation. Store in a dry, anti-static protective case.
