iMAX B6 80W 6A XT60 LiPo Battery Balance Charger

Upgraded 80W / 6A Output: Delivers up to 80W total charging power with a maximum charge current of 6.0A, enabling high-speed charging for larger capacity LiPo battery packs.

1S to 6S Cell Balance Charging: Built to balance charge 1S to 6S (3.7V–22.2V) Lithium-Polymer (LiPo), Lithium-Ion (Li-Ion), and Lithium-Iron Phosphate (LiFe) battery configurations.

Pre-Soldered High-Current XT60 Output: Features heavy-gauge main battery output leads pre-terminated with genuine high-current XT60 connectors for direct compatibility with RC drones, vehicles, and robotics.

Integrated Individual Cell Balancing: Microprocessor-controlled balancing system monitors and equalizes each individual cell's voltage during charge and discharge to maximize battery health.

Comprehensive Multi-Chemistry Compatibility: Works across multiple battery types, including LiPo, Li-Ion, LiFe, NiMH, NiCd, and Lead-Acid (Pb) batteries.

Versatile Operating Modes: Supports Balance Charge, Fast Charge, Storage Mode (ideal for long-term cell preservation), Discharge, and Cyclic Auto-Charging.

Housing & Casing Style: Durable anodized aluminum alloy housing designed to radiate operational heat effectively through passive dissipation.

Contact & Terminal Style: 4mm banana main output ports, 2S–6S JST-XH balance pin socket array, DC 11–18V input jack, and pre-soldered XT60 charging adapter harness.

Technical Specifications:

Input Voltage: DC 11V – 18V.

Circuit Power: Max Charge Power 80W / Max Discharge Power 10W.

Charge Current Range: 0.1A – 6.0A.

Discharge Current Range: 0.1A – 2.0A.

Balance Current: 300mA per cell.

Supported Cell Counts: LiPo/Li-Ion/LiFe (1-6S), NiMH/NiCd (1-15S), Pb (2V – 20V).

Color: Metallic Blue.

Usage Advice: Requires an external DC power source (11V–18V). Connect both the XT60 main power lead and the JST-XH balance connector before initiating balance charge routines.

Maintenance: Keep side cooling vents clean and free of obstruction. Store in a dry protective case when transporting into field environments.

Essential High-Speed Bench Workhorse: Position as an upgraded 80W/6A edition of the classic B6 design, providing faster turnaround times for FPV drone pilots, RC race drivers, and battery DIYers.

Highlight High-Wattage Charging & Storage Safety: Emphasize the upgraded 6A charging speed along with essential Storage Charge modes that protect expensive LiPo packs from premature degradation.
