GY-906 MLX90614ESF -DCI Sensor Module

Extended Narrow Field of View (5° FOV): Equipped with the medical/extended-range -DCI variant sensor featuring a narrow 5° FOV and integrated gradient compensation optics for long-distance spot measuring.

Non-Contact Infrared Thermal Sensing: Utilizes non-contact thermopile infrared detection to measure surface temperatures accurately without physical contact or thermal disruption.

Standard SMBus / I2C Interface: Features a 10-bit PWM output and SMBus/I2C digital output interface for seamless, direct integration with Arduino, ESP32, and Raspberry Pi platforms.

Wide Thermal Measurement Range: Accurately reads object surface temperatures from -70°C to +380°C with a wide ambient operational window of -40°C to +125°C.

Onboard Power & Signal Conditioning: Built on a blue breakout board with integrated pull-up resistors and voltage regulation to ensure low-noise signal transmission and stable logic operation.

Board Material: Blue FR-4 glass-epoxy breakout PCB with gold-plated pin header pads and TO-39 metal can sensor package with optical lens tube.

Technical Specifications:

Sensor Core: Melexis MLX90614ESF-DCI.

Field of View (FOV): 5° narrow angle.

Operating Voltage: 3.3V – 5.0V DC.

Object Temperature Range: -70°C – +380°C.

Accuracy: Up to -+ 0.5°C (in human body temperature ranges).

Board Color: Blue PCB with Metallic Sensor Tube.

Usage Advice: Keep the optical lens tube unobstructed and perpendicular to the target surface; ensure target area completely fills the 5° measurement spot cone.

Maintenance: Gently wipe the optical lens face using a lint-free cotton swab dampened with isopropyl alcohol if dust or oil accumulates on the optical window.

Essential Long-Range Non-Contact Thermal Sensor: Position as a high-precision infrared sensor module for non-contact medical screening kiosks, long-distance industrial spot checking, moving machinery monitoring, and thermal profiling.

Highlight -DCI Extended Narrow FOV: Emphasize how the 5° narrow field-of-view lens allows users to measure small or distant targets accurately compared to wide-angle 90° IR sensors.

Recommended Cross-Sell Add-ons: Pair with GY-906 MLX90614ESF Infrared Temperature Sensor, MLX90614ESF Non-Contact Infrared Thermometer, AMG8833 IR Thermal Imager Module, and ESD antistatic mat 50x40CM PCB Welding Mat.

Featured Collection Star: Display prominently on your Temperature Sensor Modules collection page as your high-accuracy, narrow-FOV infrared thermal sensor breakout module.
