GH-201B 20kg Holding Toggle Clamp

Heavy-Duty 20kg Holding Capacity: Engineered with a reliable over-center toggle mechanism that locks securely in place, delivering up to 20kg (44 lbs) of continuous clamping force.

Quick-Release Horizontal Mechanism: Features a horizontal handle design that stays parallel to the base when locked, providing clearance and effortless single-motion clamping and releasing.

Adjustable Rubber Pressure Tip: Equipped with a threaded spindle and soft rubber contact pad that adjusts easily to match workpiece thickness while protecting surface finishes from dents and scratches.

Zinc-Plated Steel Construction: High-tensile cold-rolled steel body with corrosion-resistant zinc plating ensures maximum durability in woodworking and metalworking environments.

Ergonomic Vinyl Hand Grip: Molded non-slip oil and stain-resistant red vinyl handle grip ensures operator comfort and safety during high-frequency clamping cycles.

Pre-Drilled Flanged Mounting Base: Designed with four countersunk mounting holes on the base plate for quick, secure attachment to jigs, fixtures, machine tables, or workbenches.

Body Material: Zinc-plated cold-rolled carbon steel.

Handle & Pad Material: Oil-resistant red PVC vinyl grip + non-marring rubber tip.

Technical Specifications:

Model: GH-201B.

Holding Capacity: 20kg (44 lbs).

Handle Opening Angle: 60°.

Bar Opening Angle: 85°.

Weight: 0.05 kg.

Usage Advice: Mount securely to a flat surface using appropriate screws or bolts. Adjust the rubber spindle bolt so the arm clamps down with firm, smooth pressure without over-forcing the toggle arm.

Maintenance: Keep moving joint pins lubricated with a light machine oil to maintain smooth operation and prevent wear.
