DSO211 1MHz 10MSa/ Mini ARM Storage Oscilloscope

Ultra-Portable Pocket Oscilloscope: Micro-sized ARM Cortex-M3 digital storage oscilloscope designed for lightweight field diagnostics, quick circuit debugging, and mobile electronics servicing.

1MHz Bandwidth & 10MSa/s Sampling Rate: Provides dynamic single-channel signal acquisition with 1 MHz analog bandwidth and up to 10MSa/s real-time sampling rate.

2.8-Inch Color TFT Display: Features a bright $320 \times 240$ color LCD screen displaying clear waveform traces, measurement parameters, and intuitive menu controls.

Built-in 8MB Flash Storage: Integrated internal storage flash drive allows saving and recalling waveform captures, bitmap images, and diagnostic test data via USB.

Rechargeable Lithium Battery Powered: Internal high-capacity rechargeable lithium battery provides untethered portable operation for mobile field work and field testing.

Multi-Waveform Signal Generator Output: Built-in signal source outputs standard sine, triangle, saw-tooth, and square wave test signals for circuit input testing.

Housing & Hardware Construction: Compact, high-impact ABS plastic shell with rubberized side grips, metal tactile buttons, and integrated mini-USB charging/data port.

Technical Specifications:

Analog Bandwidth: 0 - 1 MHz.

Max Sampling Rate: 10 MSa/s.

Vertical Sensitivity: 10 mV/Div - 10 V/Div.

Input Impedance: 1 M ohms.

Display: 2.8" Color TFT LCD (320 x 240).

Storage Capacity: 8MB internal USB flash memory.

Power & Battery Maintenance: Charge using a standard 5V USB adapter. Charge the battery fully before extended field storage to prolong lithium cell lifespan.

Cleaning & Care: Keep housing clean using a soft, dry microfiber cloth; do not clean using aggressive liquid solvents or immerse in water.

Essential Ultra-Portable Field Diagnostic Tool: Position as the ultimate pocket-sized oscilloscope for field engineers, automotive diagnostic technicians, embedded systems developers, and electronics hobbyists.

Highlight USB Flash Storage & Rechargeable Battery: Emphasize its 8MB internal file storage and rechargeable battery freedom as key performance upgrades over basic DIY kit oscilloscopes.

Recommended Cross-Sell Add-ons: Pair with P6100 DC-100MHz Passive Oscilloscope Probe, 1M BNC male to Dual crocodile clamp, Oscilloscope test cable, 1Hz-60MHz Frequency 200MSa/s 2 channel DDS Function Generator, and DSO138 2.4" TFT Digital Oscilloscope.

Flagship Pocket Diagnostic Star: Display prominently in your Oscilloscopes & Generators collection as a top handheld mini oscilloscope option.
