AC 220V TO DC 12V 8A Transformer Power Supply

96W Power Delivery: Converts mains AC power into a continuous, regulated 12V DC output up to 8A (96W max), providing steady power for medium-load DC applications.

AC 220V Input Compatibility: Designed to accept standard 220V AC (180V–240V) 50/60Hz grid input with minimal power ripple and high conversion efficiency.

Fine-Tuning Voltage Trim: Onboard adjustment potentiometer knob ($V_{\text{ADJ}}$) allows fine calibration of the 12V output rail ($\pm 10\%$, approx. $10.8\text{V}\text{–}13.2\text{V}$) to offset line resistance over long cable runs.

Silent Passive Convection Cooling: Perforated aluminum alloy enclosure facilitates continuous natural airflow for completely silent, fan-less operation.

Protected Terminal Connectors: Heavy-duty nickel-plated screw terminals featuring a protective clear insulation guard ensure safe and stable wiring connections.

Multi-Layer Circuit Protection: Built-in safeguards protect against output short circuits, continuous current overload, over-voltage spikes, and internal over-temperature conditions.

Housing & Casing Style: Vented aluminum alloy casing engineered for passive thermal management and electromagnetic interference (EMI) shielding.

Contact & Terminal Style: Nickel-plated screw terminal block connectors (L, N, FG, -V, +V).

Technical Specifications:

Input Voltage: AC 220 V -+ 15% (50/60Hz).

Output Voltage: DC 12V (Adjustable -+ 10%).

Output Current: 0A–8A Max.

Rated Power: 96W.

Cooling: Passive air convection via perforated aluminum mesh.

Color: Silver metallic casing with yellow terminal marker.

Usage Advice: For continuous operational setups, size total connected loads to 80% of total maximum capacity (6.4A / 76.8W). Always verify Live (L), Neutral (N), and Earth Ground ($\text{FG}$) terminals before applying mains power.

Maintenance: Ensure the mesh casing remains free of dust accumulation or metallic particles. Designed for indoor use; keep away from high humidity and direct water splash.
