5200mAh 4S 35C 14.8V LiPo Battery XT60

Massive 5200mAh Flight Capacity: Engineered to provide long flight times and high endurance for heavy-lift 4S quadcopters, professional photography drones, and high-power RC rigs.

35C High-Continuous Discharge: Delivers up to 182A continuous discharge current (70C peak burst), supplying stable power without severe voltage sag under high payload demand.

Pre-Wired XT60 Power Connector: Equipped with an industry-standard XT60 female main connector for high current efficiency, low resistance, and direct compatibility.

Integrated JST-XH 4S Balance Plug: Features a dedicated 4S JST-XH balance lead for accurate, cell-by-cell monitoring and safe charging with standard balance chargers.

14.8V (4S) Nominal High-Voltage Output: Constructed with four high-density lithium-polymer cells connected in series (16.8V peak charge voltage) for robust motor responsiveness.

Impact-Resistant Soft-Pack Casing: Encased in heavy-duty shrink film that protects inner cell layers against mechanical shocks while maintaining a balanced power-to-weight ratio.

Housing Style: Soft-pack high-density lithium polymer cells with protective shrink sleeve.

Contact & Wire Material: Flexible silicone-insulated multi-strand copper wire; gold-plated brass XT60 contacts.

Technical Specifications:

Capacity: 5200mAh.

Configuration: 4S1P / 14.8V Nominal / 16.8V Peak.

Discharge Rate: 35C Continuous.

Main Connector: XT60 Female.

Balance Connector: JST-XH 4S.

Color: Matte Black / Orange-White labeling.

Usage Advice: Charge exclusively on "LiPo Balance" mode using a dedicated balance charger. Never discharge below 3.2V per cell (12.8V total pack voltage) to preserve internal battery structure.

Maintenance: Always store at storage voltage (3.8V–3.85V per cell) inside a fireproof LiPo safety bag when not in active use.
