1.3" White IIC 128X64 OLED LCD (With VCC GND)

Generous 1.3-Inch 128 x 64 White OLED Display: Delivers bright, high-contrast white text, graphics, and custom icons over a true pitch-black background with ultra-wide viewing angles (> 160°).

Standard VCC-GND Pinout Layout: Features the classic 4-pin header arrangement (VCC, GND, SCL, SDA), ensuring direct compatibility with standard development board header pin orders.

4-Wire I2C / IIC Serial Interface: Communicates using just two signal wires (SDA and SCL) plus power, preserving microcontroller GPIO pins for additional sensors and peripherals.

Self-Luminous & Power-Efficient: OLED technology emits light at individual pixel levels, eliminating the need for a backlight and dramatically reducing power consumption for portable builds.

Broad Driver IC & Library Compatibility: Driven by the standard SH1106 / SSD1306 controller IC, natively supported by popular Adafruit OLED, U8g2, and U8glib graphics libraries.

Module Construction: Built on a multi-layer FR-4 glass epoxy printed circuit board with an integrated glass OLED screen and standard 2.54mm header pins.

Power Supply & Voltage Tolerances: Operates on 3.3V–5V DC logic power. Verify the pin order (VCC before GND) on your board prior to wiring to ensure proper connection.

Handling Precautions: Hold carefully by the outer circuit board edges. Avoid applying direct pressure or physical force onto the central glass display panel.

Environmental Limits: Operating temperature range spans -30°C to +70°C. Keep protected from static discharge, conductive metal debris, and liquid moisture.

Clear VCC-GND Pin Order Differentiation: Highlight the VCC-GND pin configuration to help customers select the exact pin arrangement matching their target project board or cable layout.

Larger Visual Upgrade from 0.96" Displays: Position as a key screen upgrade for users who need a roomier, easier-to-read 1.3-inch graphic layout without losing the compact OLED footprint.

Recommended Cross-Sell Add-ons: Pair with Arduino UNO / Nano Boards, ESP32 IoT Boards, Solderless Breadboards & Jumpers, and BME280 / DHT22 Sensor Modules.

Ideal for Mini Dashboards & Wearables: Excellent choice for building custom smart watch prototypes, compact battery gauges, desktop mini weather stations, and IoT sensor readouts.
